OZ-USA® brand aftermarket part. Designed, laser-etched and shipped by OZ-USA in Santee, California.
The OZ-USA® LAUNCH horizontal rocker switch is laser-etched to read sideways: the launch icon sits on the left and “LAUNCH” on the right, so the label is level when the rocker is mounted horizontally. It is the same 4-pin, 20A, blue-backlit On/Off switch as our vertical version, engraved for horizontal switch panels, overhead consoles, roof consoles, side-by-side dash rows, boat helms and RV control panels. Control engine, drivetrain and performance accessories on your UTV, truck, boat or RV.
Why a horizontal rocker switch?
Many UTV roof and overhead consoles, marine helms, truck overhead consoles and aftermarket switch panels hold the rockers turned 90°. A standard vertical switch then reads sideways. This horizontal launch switch keeps the icon and text upright, so a whole row of switches reads left to right. It lights up the same way at night: the icon and lettering glow blue.
Specifications
| Engraving | Launch icon on the left, “LAUNCH” on the right, laser-etched |
|---|---|
| Orientation | Horizontal: mounts sideways, icon left and text right, reads level when the rocker is installed horizontally |
| Function | On/Off (SPST, latching) |
| Current rating | 20A at 12V DC, 5A at 48V DC; no relay needed up to 240W |
| Voltage | 12V–48V (12V, 24V, 36V, 48V) |
| Pins | 4-pin: 2 for power in/out, 2 for the LED backlight |
| Backlight | Blue LED |
| Waterproof | IP66, marine grade |
| Rocker size | 2 in x 1 in (50 x 25 mm) |
| Mounting cutout | 1.41 in x 0.86 in (36 x 22 mm) standard rocker switch hole |
| Rocker color | Black |
Size and fitment
Fits any standard rocker switch cutout of 1.41 in x 0.86 in (36 x 22 mm); the rocker face is 2 in x 1 in (50 x 25 mm). Compatible with:
- Polaris RZR, Ranger, General and XPEDITION dash rocker slots
- Can-Am Maverick X3, Defender and Commander
- OZ-USA carbon fiber switch panels and golf cart key switch plates (EZGO TXT)
- boat helms and marine switch panels
- RVs, trucks, Jeeps, tractors, semis and custom 12V panels
Not sure it fits? Measure your panel opening: if it matches the cutout above, this switch drops in.
Laser-etched to last
The icon and text are etched through the black coating, not printed or stickered, so they won’t peel or fade.
Vertical version and custom labels
Mounting it upright? Get the LAUNCH vertical rocker switch with the icon on top. See every label made for sideways mounting in horizontal rocker switches, compare options in the rocker switch selector, or design your own in the custom switch builder (choose Horizontal in Step 1).
Common questions
Is this a different switch from the vertical one? No. The switch body, pins, 20A rating and blue LED are identical; only the engraving is turned 90° so it reads level when mounted sideways.
Does it fit a standard rocker cutout? Yes. It fits the standard 36 x 22 mm (1.41 x 0.86 in) rocker hole, turned horizontally.
Which way is on? Pressing the side with the icon turns the circuit on, the same as the vertical switch. Wiring is the usual 4-pin rocker layout.
